Introducing RB1100AHx4, 13x Gigabit Ethernet ports Router, powered by Annapurna Alpine AL21400 CPU with four Cortex A15 cores, clocked at 1.4GHz each, for a maximum throughput of up to 7.5Gbit. The device supports IPsec hardware acceleration (up to 2.2Gbps with AES128). Unit comes with 1U rackmount case, RS232 serial port and dual redundant power supplies (with -48v DC telecom power and 802.3at/af support).
| Product code | RB1100x4 |
| Architecture | ARM 32bit |
| CPU | AL21400 |
| CPU core count | 4 |
| CPU nominal frequency | 1.4 GHz |
| Size of RAM | 1 GB |
| Storage size | 128 MB |
| Storage type | NAND |
| License level | 6 |
| Operating System | RouterOS |
| Dimensions | 444 x 148 x 47 mm |
| Tested ambient temperature | -40°C to 70°C |
| IPsec hardware acceleration | Yes |
| List Price [Excluding VAT & TAX] | ৳ 37000.00 |
| Discount Price | Please call us for Discount Price |
| 10/100/1000 Ethernet ports | 13 |
| Basic Configuration (With Filter, NAT, Mangle, Queue) | up to 300 Mbps |
| Routing Only (Without NAT, Mangle, Queue) | up to 900 Mbps |
| PoE in | 802.3af/at |
| PoE in input Voltage | 20-57 V |
| Number of DC inputs | 2 (2-pin terminal, PoE-IN) |
| 2-pin terminal input Voltage | -48, 12-57 V |
| Max power consumption | 20 W |
| Memory card type | microSD |
| Memory Cards | 1 |
| Serial port | RS232 |
| Current Monitor | YES |
| PCB temperature monitor | YES |
| Voltage Monitor | YES |
| Mode button | YES |
| Certification | CE, EAC, ROHS |
Brand - Mikrotik, Model - Mikrotik RB1100AHx4, Router Type - Ethernet, Interface - 13 x Gigabit LAN, WAN Type - Not Specified, CPU - AL21400, RAM - 1GB, Storage - 128MB NAND, OS - RouterOS, Voice Assistant - No, LED Indicators - Not Specified, Power - Not Specified, Operating Temperature - Not Specified, Storage Temperature - -40 Degree C to 70 Degree C, Operating Humidity - Not Specified, Storage Humidity - Not Specified, Dimension (WxDxH mm) - 443 x 148 x 44mm, Color - Silver, Speciality - RouterOS license 6, FAN count Passive, PoE in 802.3af/at, PoE in input Voltage 20-57 V, Others - CPU core count: 4, CPU nominal frequency: 1.4 GHz, IP: IP20, Certification: CE, EAC, ROHS, Serial console port: RS232, Max power consumption: 20 W, Number of DC inputs: 2 (2-pin terminal, PoE-IN), Memory Cards: 1, Memory card type: microSD, Certifications - CE, EAC, ROHS, Warranty - 1 Year (Without Adapter), Country of Origin - Latvia, Made in/ Assemble - Latvia/China
