Mikrotik CSS326-24G-2S+RM
18,900৳
CRS112-8P-4S-IN is an eight Gigabit RJ45 port PoE switch, that offers different power output options: autosensing 802.3af/at PoE/PoE+ and Passive PoE, and four SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps. CRS112-8P-4S-IN is equipped with 12 independent switching ports. 28 V 3.4 A power supply is already included in the box. There is secondary DC jack on the back of the enclosure that supports 48-57 V power supply (not included, can be purchased separately - product codes 48POW (1.46A 70W) and 48V2A96W (2A 96W)). CRS112-8P-4S-IN can power 802.3af/at devices if 48-57 V DC input is used (unit will automatically detect and provide correct power to devices). Max current is 1 A per port if input voltage is 18-28 V, 450 mA if 48-57 V. Total limit is 2.8A@24V and 1.4A@48-57V. PoE-Out is passed over mode B 4,5 (+) and 7,8 (-) pins
| Product code | CRS112-8P-4S-IN |
| Architecture | MIPSBE |
| CPU | QCA8511 |
| CPU core count | 1 |
| CPU nominal frequency | 400 MHz |
| Dimensions | 200 x 142 x 44 mm |
| License level | 5 |
| Operating Syste | RouterOS |
| Size of RAM | 128 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| Tested ambient temperature | -20°C to 60°C |
| Price | Please call us for Discount Price |
| Warranty | 12 Months Limited Warranty |
| 10/100/1000 Ethernet ports | 8 |
| Number of 1G Ethernet ports with PoE-out | 8 |
| SFP ports | 4 |
| PoE out | 802.3af/at |
| PoE-out ports | Ether1-Ether24 |
| Number of DC inputs | 2 (DC jack) |
| DC jack input Voltage | 18-28 V / 48-57 V |
| Max out per port output (input < 30 V) | 1 A |
| Max out per port output (input > 30 V) | 450 mA |
| Max power consumption | 160 W |
| Max power consumption without attachments | 10 W |
| Serial port | RJ45 |
| PCB temperature monitor | YES |
Brand - Mikrotik, Model - Mikrotik CRS112-8P-4S-IN, Type - Network Switch, Number of Total Port - 12 Port, PoE - Yes, Manageability - Managed, Gigabit Port - 8, SFP Port - 4, SFP+ Port - No, PoE Port - No, PoE+ Port - No, Interface - 8 x 10/100/1000 Ethernet ports, 4 x SFP ports, Data Transfer Rate (Mbps) - 10/100/1000 Mbps, Memory - 128MB, Fan/Fanless - Fanless, MTBF - 200000 Hours, Body Color - White, Power Supply - 18-28 V / 48-57 V, Power Consumption - 160W, Form Factor - Desktop, Dimension - 200 x 142 x 44mm, Others - Architecture - MIPSBE , CPU - QCA8511 , Storage size - 128 MB , Storage type - FLASH, Number of DC inputs - 2 (DC jack) , Cooling type - Passive, PoE-out ports - Ether1-Ether8 , PoE out - 802.3af/at , Max out per port output (input 18-30 V) - 1 A , Max out per port output (input 30-57 V) - 450 mA , Max total out (A) - 2.8A (18V-28V) & 1.4A (48V-57V) A , Serial console port - RJ45., Specialty - PCB temperature monitor, CRS112-8P-4S-IN is an eight Gigabit RJ45 port PoE switch, that offers different power output options: autosensing 802.3af/at PoE/PoE+ and Passive PoE, and four SFP ports provide optical fiber connectivity options to support uplinks of up to 1 Gbps., Warranty - 1 Year (Without Adapter), Country of Origin - Latvia, Made in/ Assemble - Latvia/China
